The CO2 laser marking machine, laser beam quality, small divergence Angle, laser integration design, stable performance, high reliability, long service life, 24 hours of continuous work, continuous tunable laser frequency, no supplies, marking the area is large, clear mark, it is not easy to wear, high efficiency and low processing cost and easy operation.
Item | CO2 Laser printing machine |
Laser Type | CO2 |
Laser Source Brand | Coherent, Rofin, Synrad etc. |
Marking Area | 110mm*110mm/customizable |
Engraving Depth | ≤4mm(0.16in) Depends on the material |
Wavelength | 1064nm |
Core Components | Engine, PLC, source |
Beam Quality | <2M2 |
Laser Power | 30W/40W/60W |
Power consumption | 800 W |
Interface | USB, RS232, Wi-Fi, LAN(customizable) |
Marking Speed | <1300mm/s |
Processing Method | Online/Static |
Galvanometer brand | SINO-GALVO |
Screen | 10 Inch LCD with touch screen |
Marking material | Plastic, PET, Glass, Leather, Paper etc. |
Laser Module Life | 100000Hours |
Cooling Style | Air Cooling |
System Composition | Control System, HP Laptop, Separated Type |
Output power adjustment range | 10%-100% |
Operating Temperature | 10℃-35℃ |
Humidity | 5% to75% (Free of Condensed Water) |
Power | 110V-240V/50Hz-60Hz(According to local electricity supply). |
Warranty | 12 Months |
1. Stable performance and suitable for non-metallic material. 2. Free maintenance, low usage cost, long lifetime. 3. Higher precision and faster speed.
4. Powerful marking software, simple and easy to handle.
5. Reasonable high integration structure design.
6. Friendly operation interface, it is suit for many file formats, such as dxf, plt, bmp, step, iges, txt, etc.
7. High electronic-optic conversion efficiency, long life and easy maintenance.
8. Fast marking speed and high processing efficiency.
The CO2 laser marking machine is mainly aimed at marking and deep carving of non-metallic materials. Including: ceramics, polyvinyl chloride (PVC), ABS, acrylic, epoxy resin, glass, wood, paper, etc., widely used in wood, craft gifts, electronic components, clothing, leather, paper, food, packaging and other industries.
Laser source
Brand:DAVI
Origin: China
High quality laser source.More stable, better beam quality.Highher power and lowwer power loss.
Gavlo scanhead
Brand: Sinogavlo
Origin: China
faster, more accurate, and can be used 24 hours a day.
Sino-gavlo is a world famous brand,the No.1 sale in the world.
F-thaeta Scan Lens
Brand: Jollstar
Origin: China
Typically distortion less than 1%, Air-spaced design and high efficiency AR coatings guarantee excellent throughput and durability.
Controller
Brand: JCZ EZcad
Origin: China
Stable performance and high reliability. More than 90% laser marking machine are using EZcad controller, ensuring higher stability and shield-utilizing part of complex functions.
Switching power supply and wiring
Brand: MEANWELL
Origin: China TAIWAN
Using the world-famous brand MEANWELL 24V power supply and scientific wiring layout can minimize the equipment failure caused by the wiring.
Focus finder
Brand: Bingyan laser
Origin: China
It allows you to quickly find the focal length without using a ruler, just to see if the red dots and red lines overlap on the surface of the product which you want to mark.
Connector
Brand: Cnlinko
Origin: China
SELF-LOCKING USB connector for more stable data transmission.The straight-in type is more convenient to use than the thread type, and the connection is more tight Waterproof.
Optional accessories:
Rotary device
Diameter: 50 /80 /100/120/150 mm
Especially for marking circular cylindrical objects,
Implement curved surface markup at lower cost.
2D movable working table
Size: 220*300mm
Move the X-axis and Y-axis freely through turning the knop instead of manually horizontal movement.
The co2 laser marking machine is first marked with plastic film, and the outside is packed
in wooden boxes, and the gaps are filled with foam to prevent the impact during transportation. Custom package is also available.
